THE MOST POPULAR TYPE OF AIR CONDITIONING UNIT!
1
Select the style of unit you are after.
Cool Only Range
Designed solely to cool your home.
|
Classic Range
A Split System model perfect for everyday use, all year round.
|
Lifestyle Range
A Split System model perfect for everyday use, all year round.
|
Designer Range
A sleek, modern alternative to the Lifestyle Range.
|
Cool Only Range
2
Select the Room Size or the Cooling Capacity of the Air Conditioner you are after.
|
Or
|
||
|
16 m2
Need help Selecting Room Size?
|
2.5 Kw
|
Cool Only Range
ASTG09CMCA
2.5Kw |
|
Quote Installation |
Competitor's Price: $799
$750
Installed
($750 unit + $ Installation)
|
|
|
Features
Specifications
Power Consumption
Manuals
 UP/DOWN SWING LOUVRE
The up/down louvre automatically swings up and down.
|
 AUTO SHUT LOUVRE
The auto shut louvres close or open automatically when the unit stops or starts.
|
 AUTO RESTART
Should there be temporary loss of power; the unit will automatically restart itself in the same operating mode, once the power is restored.
|
 PROGRAM TIMER
This timer allows selection of one of four options. ON, OFF, ON > OFF, or OFF > ON.
|
 FILTER SIGN
Indicates the filter cleaning period by lamp.
|
 ALL DC
With All DC, electricity loss is decreased and power consumption reduced.
|
 WEEKLY TIMER
Different on-off times can be set for up to 7 days.
|
.png){kind=icon} AUTOMATIC LOUVRE
The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
|
 AUTOMATIC AIR FLOW ADJUSTMENT
When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.
|
 SLEEP TIMER
The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
|
 ECONOMY MODE
Limits the maximum operation current, and performs operation with the power consumption suppressed.
|
 ON-OFF TIMER
ON-OFF timer can be set to operate once every 24 hours.
|
 BLUE FIN HEAT EXCHANGER
Corrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchange.
|
 HUMAN SENSOR
Human sensor catches movements of people in a room.
|
Power Consumption for 2.5KwkW ASTG09CMCA
Heating Usage
Cooling Usage
|
Estimated Usage:
|
||||||||||||||
Details courtesy of the SmartChoice website.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
 Fujitsu 2.5kW Cool Only Manual |
|
Fujitsu 3.5kW Cool Only Manual |
|
Fujitsu 5.0kW Cool Only Manual |
|
Fujitsu 7.1kW Cool Only Manual |
| Model no. Indoor | ASTG09CMCA |
| Model no. Outdoor | AOTG09CMCA |
| Reverse Cycle System | No |
| Capacity Class | |
| Cooling Capacity (Watts) | 2,500 |
| Cooling Capacity (BTU/h) | 8,500 |
| Range (Watts) | 900-3,600 |
| Range (BTU/h) | 3,100- 12,200 |
| Heating Capacity (Watts) | |
| Heating Capacity (BTU/h) | |
| Range (Watts) | |
| Range (BTU/h) | 3,100- 18,000 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 2.7 |
| Running Current, Range (Amps) | Max 6.0 |
| Input, Cooling (watts) | 510 |
| Input, Range (Watts) | 250-1,140 |
| Running Current, Heating (Amps) | |
| Running Current, Range (Amps) | Max 6.0 |
| Input, Heating (watts) | |
| Input, Range (Watts) | |
| Input (Watts) |
| Moisture Removal (1/hr) | 1.3 |
| E.E.R.- Cooling | 4.9 |
| C.O.P.-Heating | |
| Star Rating- Cooling | 5 |
| Star Rating- Heating | |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 194 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 268*840*203 |
| Weight-Inside Unit (kg) | 8.5 |
| Dimensions- Outside Unit (H*w*D mm) | 540*790*290 |
| Weight-Outside Unit (kg) | 33 |
| I.U Sound Pressure Level (dBA@1mtr) | 40 |
| O.U Sound Pressure Level (dBA@1mtr) | 47 |
| O.U Sound Power Level (dBA) | 64 |
| Refrigerant Type | R32 |
| "Connection Pipe Sizes, Gas (mm)" | 9.52 |
| "Connection Pipe Sizes, Liquid (mm)" | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 20 |
| Maxiumum Pipe Height(Metre) | 15 |
| Pipe Connection Methods | Frameless (Indoor)/Flare (Outdoor) |
| Outdoor Opertaing Temp, Cooling Degrees C | 10 to 46 |
| Outdoor Opertaing Temp, Heating Degrees C |
| Model no. Indoor | ASTG12CMCA |
| Model no. Outdoor | AOT12CMCA |
| Reverse Cycle System | No |
| Capacity Class | |
| Cooling Capacity (Watts) | 3,500 |
| Cooling Capacity (BTU/h) | 11,900 |
| Range (Watts) | 900-4,100 |
| Range (BTU/h) | 3,100- 13,900 |
| Heating Capacity (Watts) | |
| Heating Capacity (BTU/h) | |
| Range (Watts) | |
| Range (BTU/h) | |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 4.2 |
| Running Current, Range (Amps) | Max 6.5 |
| Input, Cooling (watts) | 860 |
| Input, Range (Watts) | 250-1,380 |
| Running Current, Heating (Amps) | |
| Running Current, Range (Amps) | |
| Input, Heating (watts) | |
| Input, Range (Watts) | |
| Input (Watts) |
| Moisture Removal (1/hr) | 1.8 |
| E.E.R.- Cooling | 4.07 |
| C.O.P.-Heating | |
| Star Rating- Cooling | 3.5 |
| Star Rating- Heating | |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 200 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 268*840*203 |
| Weight-Inside Unit (kg) | 8.5 |
| Dimensions- Outside Unit (H*w*D mm) | 540*790*290 |
| Weight-Outside Unit (kg) | 33 |
| I.U Sound Pressure Level (dBA@1mtr) | 42 |
| O.U Sound Pressure Level (dBA@1mtr) | 49 |
| O.U Sound Power Level (dBA) | 67 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 20 |
| Maximum Pipe Height(Metre) | 15 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor Operating Temp, Heating Degrees C |
| Model no. Indoor | ASTG18CMCA |
| Model no. Outdoor | AOT18CMCA |
| Reverse Cycle System | No |
| Capacity Class | |
| Cooling Capacity (Watts) | 5,000 |
| Cooling Capacity (BTU/h) | 17,100 |
| Range (Watts) | 1,000-6,500 |
| Range (BTU/h) | 3,500-22,100 |
| Heating Capacity (Watts) | |
| Heating Capacity (BTU/h) | |
| Range (Watts) | |
| Range (BTU/h) | |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 5.2 |
| Running Current, Range (Amps) | Max 9.5 |
| Input, Cooling (watts) | 1,220 |
| Input, Range (Watts) | 210-2,200 |
| Running Current, Heating (Amps) | |
| Running Current, Range (Amps) | |
| Input, Heating (watts) | |
| Input, Range (Watts) | |
| Input (Watts) |
| Moisture Removal (1/hr) | 2.6 |
| E.E.R.- Cooling | 4.10 |
| C.O.P.-Heating | |
| Star Rating- Cooling | 3.5 |
| Star Rating- Heating | |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 258 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 295*940*270 |
| Weight-Inside Unit (kg) | 14 |
| Dimensions- Outside Unit (H*w*D mm) | 620*790*290 |
| Weight-Outside Unit (kg) | 39 |
| I.U Sound Pressure Level (dBA@1mtr) | 46 |
| O.U Sound Pressure Level (dBA@1mtr) | 47 |
| O.U Sound Power Level (dBA) | 65 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 30 |
| Maximum Pipe Height(Metre) | 20 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor Operating Temp, Heating Degrees C |
| Model No. - Indoor | ASTG24CMCA |
| Model No. - Outdoor | AOTG24CMCA |
| Reverse Cycle System | No |
| Capacity Class | |
| Cooling Capacity (Watts) | 7,100 |
| Cooling Capacity (BTU/h) | 24,200 |
| Range (Watts) | 1,100-8,300 |
| Range (BTU/h) | 3,800-28,300 |
| Heating Capacity (Watts) | |
| Heating Capacity (BTU/h) | |
| Range (Watts) | |
| Range (BTU/h) | |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 8.5 |
| Running Current, Range (Amps) | Max 13.0 |
| Input, Cooling (Watts) | 2,010 |
| Input, Range (Watts) | 210-2,900 |
| Running Current, Heating (Amps) | |
| Running Current, Range (Amps) | |
| Input, Heating (Watts) | |
| Input, Range (Watts) | |
| Input (Watts) |
| Moisture Removal (l/hr) | 2.7 |
| E.E.R. - Cooling | 3.53 |
| C.O.P. - Heating | |
| Star Rating - Cooling | 2.5 |
| Star Rating - Heating | |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 311 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 295*940*270 |
| Weight - Inside Unit (kg) | 14 |
| Dimensions - Outside Unit (HxWxD mm) | 620*790*290 |
| Weight - Outside Unit (kg) | 39 |
| I.U. Sound Pressure Level (dBA@1mtr) | 49 |
| O.U. Sound Pressure Level (dBA@1mtr) | 52 |
| O.U. Sound Power Level (dBA) | 70 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 30 |
| Maximum Pipe Height (Metre) | 20 |
| Pipe Connection Methods | Flareless (Indoor) / Flare (Outdoor) |
| Outdoor operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor operating Temp, Heating Degrees C |
Classic Range
2
Select the Room Size or the Cooling Capacity of the Air Conditioner you are after.
|
Or
|
||
|
16 m2
Need help Selecting Room Size?
|
2.5 Kw
|
Classic Range
ASTG09LVCC
2.5Kw |
|
Quote Installation |
|
$795
Installed
($795 unit + $ Installation)
|
|
|
Features
Specifications
Power Consumption
Manuals
|
UP/DOWN SWING LOUVRE
The up/down louvre automatically swings up and down.
|
AUTO SHUT LOUVRE
The auto shut louvres close or open automatically when the unit stops or starts.
|
AUTO RESTART
Should there be temporary loss of power; the unit will automatically restart itself in the same operating mode, once the power is restored.
|
|
ALL DC
With All DC, electricity loss is decreased and power consumption reduced.
|
WEEKLY TIMER
Different on-off times can be set for up to 7 days.
|
AUTOMATIC LOUVRE
The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
|
|
AUTOMATIC AIR FLOW ADJUSTMENT
When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.
|
SLEEP TIMER
The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
|
ECONOMY MODE
Limits the maximum operation current, and performs operation with the power consumption suppressed.
|
|
BLUE FIN HEAT EXCHANGER
Corrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchange.
|
PROGRAM TIMER
This timer allows selection of one of four options. ON, OFF, ON > OFF, or OFF > ON.
|
 AUTO CHANGEOVER
The unit automatically switches between heating and cooling modes based on the temperature setting and room temperature.
|
Power Consumption for 2.5KwkW ASTG09LVCC
Heating Usage
Cooling Usage
|
Estimated Usage:
|
||||||||||||||
Details courtesy of the SmartChoice website.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
|
Fujitsu 2.5kW Classic Range Manual |
|
Fujitsu 3.5kW Classic Range Manual |
|
Fujitsu 5kW Classic Range Manual |
|
Fujitsu 6.3kW Classic Range Manual |
|
Fujitsu 7.1kW Classic Range Manual |
|
Fujitsu 8.5kW Classic Range Manual |
|
Fujitsu 9.4kW Classic Range Manual |
| Model No. - Indoor | ASTG09LVCC |
| Model No. - Outdoor | AOTG09LVCC |
| Reverse Cycle System | Yes |
| Capacity Class | - |
| Cooling Capacity (Watts) | 2,500 |
| Cooling Capacity (BTU/h) | 8,500 |
| Range (Watts) | 500 - 3,300 |
| Range (BTU/h) | 1,700 - 11,300 |
| Heating Capacity (Watts) | 3,400 |
| Heating Capacity (BTU/h) | 11,600 |
| Range (Watts) | 500 - 4,000 |
| Range (BTU/h) | 1,700-13,600 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1 - 5 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | - |
| Running Current, Cooling (Amps) | 2.8 |
| Running Current, Range (Amps) | Max: 6.0 |
| Input, Cooling (Watts) | 580 |
| Input, Range (Watts) | 250 - 1,240 |
| Running Current, Heating (Amps) | 3.5 |
| Running Current, Range (Amps) | Max: 7.5 |
| Input, Heating (Watts) | 730 |
| Input, Range (Watts) | 250 - 1,560 |
| Input (Watts) | - |
| Moisture Removal (l/hr) | 1.3 |
| E.E.R. - Cooling | 4.31 |
| C.O.P. - Heating | 4.66 |
| Star Rating - Cooling | 4 |
| Star Rating - Heating | 4.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 219 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 293 x 790 x 225 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 540 x 660 x 290 |
| Weight - Outside Unit (kg) | 25 |
| I.U. Sound Pressure Level (dBA@1mtr) | 41 |
| O.U. Sound Pressure Level (dBA@1mtr) | 47 |
| O.U. Sound Power Level (dBA) | 64 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 15 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C |
| Model No. - Indoor | ASTG12LVCC |
| Model No. - Outdoor | AOTG12LVCC |
| Reverse Cycle System | Yes |
| Capacity Class | - |
| Cooling Capacity (Watts) | 3,500 |
| Cooling Capacity (BTU/h) | 11,900 |
| Range (Watts) | 900 - 4,000 |
| Range (BTU/h) | 3,100 - 13,600 |
| Heating Capacity (Watts) | 4,800 |
| Heating Capacity (BTU/h) | 16,400 |
| Range (Watts) | 900 - 5,600 |
| Range (BTU/h) | 3,100 - 19,100 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1 - 50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | - |
| Running Current, Cooling (Amps) | 4.2 |
| Running Current, Range (Amps) | Max: 6.5 |
| Input, Cooling (Watts) | 920 |
| Input, Range (Watts) | 250 - 2,000 |
| Running Current, Heating (Amps) | 5.0 |
| Running Current, Range (Amps) | Max: 9.0 |
| Input, Heating (Watts) | 1,110 |
| Input, Range (Watts) | 250 - 2,000 |
| Input (Watts) | - |
| Moisture Removal (l/hr) | 1.8 |
| E.E.R. - Cooling | 3.80 |
| C.O.P. - Heating | 4.32 |
| Star Rating - Cooling | 3 |
| Star Rating - Heating | 4 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 225 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 293 x 790 x 225 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 540 x 790 x 290 |
| Weight - Outside Unit (kg) | 34 |
| I.U. Sound Pressure Level (dBA@1mtr) | 42 |
| O.U. Sound Pressure Level (dBA@1mtr) | 48 |
| O.U. Sound Power Level (dBA) | 66 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 15 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG18LVCC |
| Model No. - Outdoor | AOTG18LVCC |
| Reverse Cycle System | Yes |
| Capacity Class | - |
| Cooling Capacity (Watts) | 5.0 |
| Cooling Capacity (BTU/h) | 17,100 |
| Range (Watts) | 900 - 5,800 |
| Range (BTU/h) | 3,100 - 19,800 |
| Heating Capacity (Watts) | 6.0 |
| Heating Capacity (BTU/h) | 20,400 |
| Range (Watts) | 1,050 - 8,100 |
| Range (BTU/h) | 3,600 - 27,600 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1 - 50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | - |
| Running Current, Cooling (Amps) | 6.5 |
| Running Current, Range (Amps) | Max: 9.5 |
| Input, Cooling (Watts) | 1,530 |
| Input, Range (Watts) | 180 - 2,030 |
| Running Current, Heating (Amps) | 6.3 |
| Running Current, Range (Amps) | Max: 13.5 |
| Input, Heating (Watts) | 1,490 |
| Input, Range (Watts) | 170 - 3,190 |
| Input (Watts) | - |
| Moisture Removal (l/hr) | 2.6 |
| E.E.R. - Cooling | 3.27 |
| C.O.P. - Heating | 4.03 |
| Star Rating - Cooling | 2 |
| Star Rating - Heating | 3.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 267 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 293 × 790 × 225 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 620 × 790 × 290 |
| Weight - Outside Unit (kg) | 37 |
| I.U. Sound Pressure Level (dBA@1mtr) | 46 |
| O.U. Sound Pressure Level (dBA@1mtr) | 52 |
| O.U. Sound Power Level (dBA) | 69 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 15 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG22LVCB |
| Model No. - Outdoor | AOTG22LVCB |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 6,300 |
| Cooling Capacity (BTU/h) | 21,500 |
| Range (Watts) | 900-7,300 |
| Range (BTU/h) | 3,100-24,900 |
| Heating Capacity (Watts) | 7,200 |
| Heating Capacity (BTU/h) | 23,900 |
| Range (Watts) | 1,050-8,700 |
| Range (BTU/h) | 3,600-29,700 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | N/A |
| Running Current, Cooling (Amps) | 8.2 |
| Running Current, Range (Amps) | Max 11.2 |
| Input, Cooling (Watts) | 1,950 |
| Input, Range (Watts) | 180-2,750 |
| Running Current, Heating (Amps) | 8.5 |
| Running Current, Range (Amps) | Max 17.5 |
| Input, Heating (Watts) | 2,030 |
| Input, Range (Watts) | 170-4,180 |
| Input (Watts) |
| Moisture Removal (l/hr) | 2.7 |
| E.E.R. - Cooling | 3.23 |
| C.O.P. - Heating | 3.55 |
| Star Rating - Cooling | 2 |
| Star Rating - Heating | 2.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 266 |
| Compressor Type | Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 293x790x225 |
| Weight - Inside Unit (kg) | 12 |
| Dimensions - Outside Unit (HxWxD mm) | 620x790x290 |
| Weight - Outside Unit (kg) | 42 |
| I.U. Sound Pressure Level (dBA@1mtr) | 48 |
| O.U. Sound Pressure Level (dBA@1mtr) | 55 |
| O.U. Sound Power Level (dBA) | 72 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 15 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG24LFCC |
| Model No. - Outdoor | AOTG24LFCC |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 7,100 |
| Cooling Capacity (BTU/h) | 24,200 |
| Range (Watts) | 900-8,300 |
| Range (BTU/h) | 3,100-28,300 |
| Heating Capacity (Watts) | 8,000 |
| Heating Capacity (BTU/h) | 27,300 |
| Range (Watts) | 900-10,600 |
| Range (BTU/h) | 3,100-36,200 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 9.1 |
| Running Current, Range (Amps) | Max 13.5 |
| Input, Cooling (Watts) | 2,170 |
| Input, Range (Watts) | 300-2,860 |
| Running Current, Heating (Amps) | 9.5 |
| Running Current, Range (Amps) | Max 18.5 |
| Input, Heating (Watts) | 2,260 |
| Input, Range (Watts) | 280-4,046 |
| Input (Watts) |
| Moisture Removal (l/hr) | 2.7 |
| E.E.R. - Cooling | 3.27 |
| C.O.P. - Heating | 3.54 |
| Star Rating - Cooling | 2 |
| Star Rating - Heating | 2.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 311 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 320×998×238 |
| Weight - Inside Unit (kg) | 14 |
| Dimensions - Outside Unit (HxWxD mm) | 620×790×290 |
| Weight - Outside Unit (kg) | 41 |
| I.U. Sound Pressure Level (dBA@1mtr) | 49 |
| O.U. Sound Pressure Level (dBA@1mtr) | 55 |
| O.U. Sound Power Level (dBA) | 71 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 15 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 30 |
| Maximum Pipe Height (Metre) | 20 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG30LFCC |
| Model No. - Outdoor | AOTG30LFTC |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 8,500 |
| Cooling Capacity (BTU/h) | 27,300 |
| Range (Watts) | 2,900-9,000 |
| Range (BTU/h) | 9,900-30,700 |
| Heating Capacity (Watts) | 9,000 |
| Heating Capacity (BTU/h) | 30,700 |
| Range (Watts) | 2,200-11,000 |
| Range (BTU/h) | 7,500-37,600 |
| Power Supply (Volts) | 230 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | Not Applicable |
| Running Current, Cooling (Amps) | 10.2 |
| Running Current, Range (Amps) | Max 17.0 |
| Input, Cooling (Watts) | 2,420 |
| Input, Range (Watts) | 580-3,150 |
| Running Current, Heating (Amps) | 11.1 |
| Running Current, Range (Amps) | Max 19.0 |
| Input, Heating (Watts) | 2,640 |
| Input, Range (Watts) | 500-3,530 |
| Input (Watts) |
| Moisture Removal (l/hr) | 3.2 |
| E.E.R. - Cooling | 3.31 |
| C.O.P. - Heating | 3.41 |
| Star Rating - Cooling | 2 |
| Star Rating - Heating | 2 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 311 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 340x1150x280 |
| Weight - Inside Unit (kg) | 14 |
| Dimensions - Outside Unit (HxWxD mm) | 830x900x330 |
| Weight - Outside Unit (kg) | 61 |
| I.U. Sound Pressure Level (dBA@1mtr) | 49 |
| O.U. Sound Pressure Level (dBA@1mtr) | 53 |
| O.U. Sound Power Level (dBA) | 69 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 9.52 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 5 |
| Maximum Pipe Length (Metre) | 50 |
| Maximum Pipe Height (Metre) | 30 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG34LFCC |
| Model No. - Outdoor | AOTG34LFTC |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 9,200 |
| Cooling Capacity (BTU/h) | 31,400 |
| Range (Watts) | 2,900-10,000 |
| Range (BTU/h) | 9,900-34,100 |
| Heating Capacity (Watts) | 10,000 |
| Heating Capacity (BTU/h) | 34,100 |
| Range (Watts) | 2,700-11,200 |
| Range (BTU/h) | 9,200-38,200 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 11.8 |
| Running Current, Range (Amps) | Max 18.5 |
| Input, Cooling (Watts) | 2,800 |
| Input, Range (Watts) | 590-3,540 |
| Running Current, Heating (Amps) | 12.8 |
| Running Current, Range (Amps) | Max 19.0 |
| Input, Heating (Watts) | 3,030 |
| Input, Range (Watts) | 600-3,570 |
| Input (Watts) |
| Moisture Removal (l/hr) | 3.5 |
| E.E.R. - Cooling | 3.29 |
| C.O.P. - Heating | 3.30 |
| Star Rating - Cooling | 2 |
| Star Rating - Heating | 2 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 347 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 340x1150x280 |
| Weight - Inside Unit (kg) | 14 |
| Dimensions - Outside Unit (HxWxD mm) | 1,290x900x330 |
| Weight - Outside Unit (kg) | 86 |
| I.U. Sound Pressure Level (dBA@1mtr) | 52 |
| O.U. Sound Pressure Level (dBA@1mtr) | 53 |
| O.U. Sound Power Level (dBA) | 67 |
| Refrigerant Type | R410A |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 9.52 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 5 |
| Maximum Pipe Length (Metre) | 50 |
| Maximum Pipe Height (Metre) | 30 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | -5 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
Lifestyle Range
2
Select the Room Size or the Cooling Capacity of the Air Conditioner you are after.
|
Or
|
||
|
16 m2
Need help Selecting Room Size?
|
2.5 Kw
|
Lifestyle Range
ASTG09KMCA
2.5Kw |
|
Quote Installation |
|
$795
Installed
($795 unit + $ Installation)
|
|
|
Features
Specifications
Power Consumption
Manuals
|
UP/DOWN SWING LOUVRE
The up/down louvre automatically swings up and down.
|
AUTO SHUT LOUVRE
The auto shut louvres close or open automatically when the unit stops or starts.
|
AUTO RESTART
Should there be temporary loss of power; the unit will automatically restart itself in the same operating mode, once the power is restored.
|
|
PROGRAM TIMER
This timer allows selection of one of four options. ON, OFF, ON > OFF, or OFF > ON.
|
FILTER SIGN
Indicates the filter cleaning period by lamp.
|
ALL DC
With All DC, electricity loss is decreased and power consumption reduced.
|
|
WEEKLY TIMER
Different on-off times can be set for up to 7 days.
|
AUTOMATIC LOUVRE
The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
|
AUTOMATIC AIR FLOW ADJUSTMENT
When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.
|
|
SLEEP TIMER
The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
|
ECONOMY MODE
Limits the maximum operation current, and performs operation with the power consumption suppressed.
|
ON-OFF TIMER
ON-OFF timer can be set to operate once every 24 hours.
|
|
BLUE FIN HEAT EXCHANGER
Corrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchange.
|
HUMAN SENSOR
Human sensor catches movements of people in a room.
|
Power Consumption for 2.5KwkW ASTG09KMCA
Heating Usage
Cooling Usage
|
Estimated Usage:
|
||||||||||||||
Details courtesy of the SmartChoice website.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
|
Fujitsu 2.5kW Lifestyle Range Manual |
|
Fujitsu 3.5kW Lifestyle Range Manual |
|
Fujitsu 5.0kW Lifestyle Range Manual |
|
Fujitsu 6.3kW Lifestyle Range Manual |
|
Fujitsu 7.1kW Lifestyle Range Manual |
|
Fujitsu 8.0kW Lifestyle Range Manual |
|
Fujitsu 9.4kW Lifestyle Range Manual |
| Model no. Indoor | ASTG09KMCA |
| Model no. Outdoor | AOTG09KMCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 2,500 |
| Cooling Capacity (BTU/h) | 8,500 |
| Range (Watts) | 900-5,300 |
| Range (BTU/h) | 3,100- 18,000 |
| Heating Capacity (Watts) | 3200 |
| Heating Capacity (BTU/h) | 10,900 |
| Range (Watts) | 900-5,300 |
| Range (BTU/h) | 3,100- 18,000 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 2.7 |
| Running Current, Range (Amps) | Max 6.0 |
| Input, Cooling (watts) | 510 |
| Input, Range (Watts) | 250-1,140 |
| Running Current, Heating (Amps) | 3.3 |
| Running Current, Range (Amps) | Max 7.5 |
| Input, Heating (watts) | 650 |
| Input, Range (Watts) | 250-1,140 |
| Input (Watts) |
| Moisture Removal (1/hr) | 1.3 |
| E.E.R.- Cooling | 4.9 |
| C.O.P.-Heating | 4.92 |
| Star Rating- Cooling | 5 |
| Star Rating- Heating | 5 |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 194 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 268x840x203 |
| Weight-Inside Unit (kg) | 8.5 |
| Dimensions- Outside Unit (H*w*D mm) | 540x790x290 |
| Weight-Outside Unit (kg) | 34 |
| I.U Sound Pressure Level (dBA@1mtr) | 40 |
| O.U Sound Pressure Level (dBA@1mtr) | 47 |
| O.U Sound Power Level (dBA) | 64 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 20 |
| Maximum Pipe Height(Metre) | 15 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor Operating Temp, Heating Degrees C |
| Model no. Indoor | ASTG12KMCA |
| Model no. Outdoor | AOT12KMCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 3,500 |
| Cooling Capacity (BTU/h) | 11,900 |
| Range (Watts) | 900-4,100 |
| Range (BTU/h) | 3,100- 13,900 |
| Heating Capacity (Watts) | 3,700 |
| Heating Capacity (BTU/h) | 12,600 |
| Range (Watts) | 900-5,600 |
| Range (BTU/h) | 3,100- 19,100 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 4.2 |
| Running Current, Range (Amps) | Max 6.5 |
| Input, Cooling (watts) | 860 |
| Input, Range (Watts) | 250-1,380 |
| Running Current, Heating (Amps) | 4.0 |
| Running Current, Range (Amps) | Max 9.0 |
| Input, Heating (watts) | 810 |
| Input, Range (Watts) | 250-1,700 |
| Input (Watts) |
| Moisture Removal (1/hr) | 1.8 |
| E.E.R.- Cooling | 4.07 |
| C.O.P.-Heating | 4.57 |
| Star Rating- Cooling | 3.5 |
| Star Rating- Heating | 4.5 |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 200 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 268x840x203 |
| Weight-Inside Unit (kg) | 8.5 |
| Dimensions- Outside Unit (H*w*D mm) | 540x790x290 |
| Weight-Outside Unit (kg) | 34 |
| I.U Sound Pressure Level (dBA@1mtr) | 42 |
| O.U Sound Pressure Level (dBA@1mtr) | 49 |
| O.U Sound Power Level (dBA) | 67 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 20 |
| Maximum Pipe Height(Metre) | 15 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor Operating Temp, Heating Degrees C | -15 to 24 |
| Model no. Indoor | ASTG18KMCA |
| Model no. Outdoor | AOT18KMCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 5,000 |
| Cooling Capacity (BTU/h) | 17,100 |
| Range (Watts) | 1,000-6,500 |
| Range (BTU/h) | 3,500-22,100 |
| Heating Capacity (Watts) | 6,000 |
| Heating Capacity (BTU/h) | 20,400 |
| Range (Watts) | 1,050-8,300 |
| Range (BTU/h) | 3,600-28,300 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 5.2 |
| Running Current, Range (Amps) | Max 9.5 |
| Input, Cooling (watts) | 1,200 |
| Input, Range (Watts) | 210-2,200 |
| Running Current, Heating (Amps) | 6.0 |
| Running Current, Range (Amps) | Max 13.5 |
| Input, Heating (watts) | 1,420 |
| Input, Range (Watts) | 200-3,100 |
| Input (Watts) |
| Moisture Removal (1/hr) | 2.6 |
| E.E.R.- Cooling | 4.10 |
| C.O.P.-Heating | 4.23 |
| Star Rating- Cooling | 3.5 |
| Star Rating- Heating | 3.5 |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 258 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 295x940x270 |
| Weight-Inside Unit (kg) | 14 |
| Dimensions- Outside Unit (H*w*D mm) | 620x790x290 |
| Weight-Outside Unit (kg) | 40 |
| I.U Sound Pressure Level (dBA@1mtr) | 46 |
| O.U Sound Pressure Level (dBA@1mtr) | 47 |
| O.U Sound Power Level (dBA) | 65 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 30 |
| Maximum Pipe Height(Metre) | 20 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor Operating Temp, Heating Degrees C | -15 to 24 |
| Model no. Indoor | ASTG22KMCA |
| Model no. Outdoor | AOTG22KMCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 6,000 |
| Cooling Capacity (BTU/h) | 20,400 |
| Range (Watts) | 1,100-7,500 |
| Range (BTU/h) | 3,800-33,000 |
| Heating Capacity (Watts) | 7,200 |
| Heating Capacity (BTU/h) | 24,600 |
| Range (Watts) | 1,100-9,700 |
| Range (BTU/h) | 3,800-33,000 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 6.7 |
| Running Current, Range (Amps) | Max 13.0 |
| Input, Cooling (watts) | 1,590 |
| Input, Range (Watts) | 210-2,850 |
| Running Current, Heating (Amps) | 7.5 |
| Running Current, Range (Amps) | Max 16.0 |
| Input, Heating (watts) | 1,770 |
| Input, Range (Watts) | 200-3,400 |
| Input (Watts) |
| Moisture Removal (1/hr) | 2.7 |
| E.E.R.- Cooling | 3.77 |
| C.O.P.-Heating | 4.07 |
| Star Rating- Cooling | 3 |
| Star Rating- Heating | 3.5 |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 278 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 295x940x270 |
| Weight-Inside Unit (kg) | 14 |
| Dimensions- Outside Unit (H*w*D mm) | 620x790x290 |
| Weight-Outside Unit (kg) | 40 |
| I.U Sound Pressure Level (dBA@1mtr) | 48 |
| O.U Sound Pressure Level (dBA@1mtr) | 49 |
| O.U Sound Power Level (dBA) | 70 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 3 |
| Maximum Pipe Length(Metre) | 30 |
| Maximum Pipe Height(Metre) | 20 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor Operating Temp, Heating Degrees C | -15 to 24 |
| Model no. Indoor | ASTG24KMCA |
| Model no. Outdoor | AOTG24KMCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 7,100 |
| Cooling Capacity (BTU/h) | 24,200 |
| Range (Watts) | 1,100-8,300 |
| Range (BTU/h) | 3,800-28,300 |
| Heating Capacity (Watts) | 8,000 |
| Heating Capacity (BTU/h) | 27,300 |
| Range (Watts) | 1,100-10,600 |
| Range (BTU/h) | 3,800-36,100 |
| Power Supply(Volts) | 240 |
| Phase-Frequency (PH-hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug size (if applicable) | |
| Running Current, Cooling (Amps) | 8.5 |
| Running Current, Range (Amps) | Max 13.0 |
| Input, Cooling (watts) | 2,010 |
| Input, Range (Watts) | 210-2,900 |
| Running Current, Heating (Amps) | 9.0 |
| Running Current, Range (Amps) | Max 16.0 |
| Input, Heating (watts) | 2,120 |
| Input, Range (Watts) | 210-2,900 |
| Input (Watts) |
| Moisture Removal (1/hr) | 2.7 |
| E.E.R.- Cooling | 3.53 |
| C.O.P.-Heating | 3.77 |
| Star Rating- Cooling | 2.5 |
| Star Rating- Heating | 3 |
| Fan Speed | 4 |
| Air Circulation, High (1/s) | 311 |
| Compressor Type | DC Rotary |
| Dimensions- Inside Unit (H*w*D mm) | 295x940x270 |
| Weight-Inside Unit (kg) | 14 |
| Dimensions- Outside Unit (H*w*D mm) | 620x790x290 |
| Weight-Outside Unit (kg) | 40 |
| I.U Sound Pressure Level (dBA@1mtr) | 49 |
| O.U Sound Pressure Level (dBA@1mtr) | 52 |
| O.U Sound Power Level (dBA) | 70 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length(Metre) | 30 |
| Maximum Pipe Length(Metre) | 3 |
| Maximum Pipe Height(Metre) | 20 |
| Pipe Connection Methods | Frameless (Indoor)/Flare(Outdoor) |
| Outdoor Operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor Operating Temp, Heating Degrees C | -15 to 24 |
| go | |
| Model No. - Indoor | ASTG30KMTA |
| Model No. - Outdoor | AOTG30KMTA |
| Reverse Cycle System | Yes |
| Capacity Class | - |
| Cooling Capacity (Watts) | 8,500 |
| Cooling Capacity (BTU/h) | 29,000 |
| Range (Watts) | 2,900 — 10,500 |
| Range (BTU/h) | 9,900 — 35,800 |
| Heating Capacity (Watts) | 9,000 |
| Heating Capacity (BTU/h) | 30,700 |
| Range (Watts) | 2,200 — 11,200 |
| Range (BTU/h) | 7,500 — 38,200 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 50 |
| Power Supply Attachment | Outdoor Unit |
| Plug Size (If Applicable) | Not Applicable |
| Running Current, Cooling (Amps) | 10.4 |
| Running Current, Range (Amps) | Maximum = 17.0 |
| Input, Cooling (Watts) | 2,460 |
| Input, Range (Watts) | 580 — 3,850 |
| Running Current, Heating (Amps) | 10.1 |
| Running Current, Range (Amps) | Maximum = 17.0 |
| Input, Heating (Watts) | 2,460 |
| Input, Range (Watts) | 580 — 3,850 |
| Input (Watts) | - |
| Moisture Removal (l/hr) | 2.5 |
| E.E.R. - Cooling | 3.45 |
| C.O.P. - Heating | 3.84 |
| Star Rating - Cooling | 2.0 |
| Star Rating - Heating | 3.0 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 389 |
| Compressor Type | Hermetic Motor Compressor × 1 |
| Dimensions - Inside Unit (HxWxD mm) | 340 × 1,150 × 280 |
| Weight - Inside Unit (kg) | 18 |
| Dimensions - Outside Unit (HxWxD mm) | 830 × 900 × 330 |
| Weight - Outside Unit (kg) | 61 |
| I.U. Sound Pressure Level (dBA@1mtr) | 51 |
| O.U. Sound Pressure Level (dBA@1mtr) | 54 |
| O.U. Sound Power Level (dBA) | 67 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 9.52 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 5 |
| Maximum Pipe Length (Metre) | 75 |
| Maximum Pipe Height (Metre) | 30 |
| Pipe Connection Methods | Flared |
| Outdoor operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG34KMTA |
| Model No. - Outdoor | AOTG34KMTA |
| Reverse Cycle System | Yes |
| Capacity Class | - |
| Cooling Capacity (Watts) | 9,400 |
| Cooling Capacity (BTU/h) | 32,000 |
| Range (Watts) | 2,900 - 11,200 |
| Range (BTU/h) | 9,900 - 38,200 |
| Heating Capacity (Watts) | 10,300 |
| Heating Capacity (BTU/h) | 35,100 |
| Range (Watts) | 2,700 - 11,700 |
| Range (BTU/h) | 9,200 - 39,900 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 50 |
| Power Supply Attachment | Outdoor Unit |
| Plug Size (If Applicable) | Not Applicable |
| Running Current, Cooling (Amps) | 11.7 |
| Running Current, Range (Amps) | Maximum - 19.5 |
| Input, Cooling (Watts) | 2,780 |
| Input, Range (Watts) | 0.590 - 4,030 |
| Running Current, Heating (Amps) | 12.9 |
| Running Current, Range (Amps) | Maximum - 20.5 |
| Input, Heating (Watts) | 2,840 |
| Input, Range (Watts) | 600 - 4,240 |
| Input (Watts) | - |
| Moisture Removal (l/hr) | 3.5 |
| E.E.R. - Cooling | 3.38 |
| C.O.P. - Heating | 3.63 |
| Star Rating - Cooling | 2.0 |
| Star Rating - Heating | 2.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 389 |
| Compressor Type | Hermetic Motor Compressor × 1 |
| Dimensions - Inside Unit (HxWxD mm) | 340 × 1,150 × 280 |
| Weight - Inside Unit (kg) | 18 |
| Dimensions - Outside Unit (HxWxD mm) | 914 × 970 × 370 |
| Weight - Outside Unit (kg) | 75 |
| I.U. Sound Pressure Level (dBA@1mtr) | 52 |
| O.U. Sound Pressure Level (dBA@1mtr) | 54 |
| O.U. Sound Power Level (dBA) | 67 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 15.88 |
| Connection Pipe Sizes, Liquid (mm) | 9.52 |
| Pre Charged Length (Metre) | 30 |
| Minimum Pipe Length (Metre) | 5 |
| Maximum Pipe Length (Metre) | 75 |
| Maximum Pipe Height (Metre) | 30 |
| Pipe Connection Methods | Flare |
| Outdoor operating Temp, Cooling Degrees C | -10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
Designer Range
2
Select the Room Size or the Cooling Capacity of the Air Conditioner you are after.
|
Or
|
||
|
16 m2
Need help Selecting Room Size?
|
2.5 Kw
|
Designer Range
ASTG09KUCA
2.5Kw |
|
Quote Installation |
|
$995
Installed
($995 unit + $ Installation)
|
|
|
Features
Specifications
Power Consumption
Manuals
|
UP/DOWN SWING LOUVRE
The up/down louvre automatically swings up and down.
|
AUTO SHUT LOUVRE
The auto shut louvres close or open automatically when the unit stops or starts.
|
AUTO RESTART
Should there be temporary loss of power; the unit will automatically restart itself in the same operating mode, once the power is restored.
|
|
PROGRAM TIMER
This timer allows selection of one of four options. ON, OFF, ON > OFF, or OFF > ON.
|
FILTER SIGN
Indicates the filter cleaning period by lamp.
|
ALL DC
With All DC, electricity loss is decreased and power consumption reduced.
|
|
WEEKLY TIMER
Different on-off times can be set for up to 7 days.
|
AUTOMATIC LOUVRE
The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
|
AUTOMATIC AIR FLOW ADJUSTMENT
When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.
|
|
SLEEP TIMER
The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
|
ECONOMY MODE
Limits the maximum operation current, and performs operation with the power consumption suppressed.
|
ON-OFF TIMER
ON-OFF timer can be set to operate once every 24 hours.
|
|
BLUE FIN HEAT EXCHANGER
Corrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchange.
|
HUMAN SENSOR
Human sensor catches movements of people in a room.
|
.png){kind=icon} LONG-LIFE* ION DEODORISATION FILTER
The filter deodorises by powerfully decomposing absorbed odours using the oxidizing filter and reducing effects of ions generated by the ultra-fine-particle ceramic.
|
.png){kind=icon} APPLE-CATECHIN FILTER
Fine dust, invisible mold spores and harmful micro-organisms are absorbed onto the filter by static electricity and further growth is inhibited and deactivated by the polyphenol ingredient extracted from apples.
|
Power Consumption for 2.5KwkW ASTG09KUCA
Heating Usage
Cooling Usage
|
Estimated Usage:
|
||||||||||||||
Details courtesy of the SmartChoice website.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
*Savings are indicative only. Actual running costs are affected by many factors including climate and insulation. Assumed power use is 125 W/m sq. for cooling and 100 W/m sq. for heating.
Savings Based on $0.31/kWh
Note - Air Conditioner may operate at less than rated capacity so actual cost of runnning for hours selected may be less than shown.
|
Fujitsu 2.5kW Designer Range Manual |
|
Fujitsu 3.5kW Designer Range Manual |
|
Fujitsu 5.0kW Designer Range Manual |
| Model No. - Indoor | ASTG09KUCA |
| Model No. - Outdoor | AOTG09KUCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 2,500 |
| Cooling Capacity (BTU/h) | 8,500 |
| Range (Watts) | 900-3,600 |
| Range (BTU/h) | 3,100-12,200 |
| Heating Capacity (Watts) | 3,200 |
| Heating Capacity (BTU/h) | 10,900 |
| Range (Watts) | 900-5,400 |
| Range (BTU/h) | 3,100-18,400 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 2.7 |
| Running Current, Range (Amps) | Max 6.0 |
| Input, Cooling (Watts) | 510 |
| Input, Range (Watts) | 250-1,140 |
| Running Current, Heating (Amps) | 3.3 |
| Running Current, Range (Amps) | Max 7.5 |
| Input, Heating (Watts) | 670 |
| Input, Range (Watts) | 250-1,600 |
| Input (Watts) |
| Moisture Removal (l/hr) | 1.3 |
| E.E.R. - Cooling | 4.90 |
| C.O.P. - Heating | 4.78 |
| Star Rating - Cooling | 5 |
| Star Rating - Heating | 5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 222 |
| Compressor Type | DC Rotarty |
| Dimensions - Inside Unit (HxWxD mm) | 282*870*185 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 540*790*290 |
| Weight - Outside Unit (kg) | 34 |
| I.U. Sound Pressure Level (dBA@1mtr) | 42 |
| O.U. Sound Pressure Level (dBA@1mtr) | 47 |
| O.U. Sound Power Level (dBA) | 64 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flareless (Indoor) / Flare (Outdoor) |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG12KUCA |
| Model No. - Outdoor | AOTG12KUCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 3,500 |
| Cooling Capacity (BTU/h) | 11,900 |
| Range (Watts) | 900-4,100 |
| Range (BTU/h) | 3,100-13,900 |
| Heating Capacity (Watts) | 4,300 |
| Heating Capacity (BTU/h) | 14,700 |
| Range (Watts) | 900-5,700 |
| Range (BTU/h) | 3,100-19,400 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 4.3 |
| Running Current, Range (Amps) | Max 6.5 |
| Input, Cooling (Watts) | 880 |
| Input, Range (Watts) | 250-1,380 |
| Running Current, Heating (Amps) | 4.9 |
| Running Current, Range (Amps) | Max 9.0 |
| Input, Heating (Watts) | 1,060 |
| Input, Range (Watts) | 250-1,700 |
| Input (Watts) |
| Moisture Removal (l/hr) | 1.3 |
| E.E.R. - Cooling | 3.98 |
| C.O.P. - Heating | 4.06 |
| Star Rating - Cooling | 3.5 |
| Star Rating - Heating | 3.5 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 236 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 282*870*185 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 540*790*290 |
| Weight - Outside Unit (kg) | 34 |
| I.U. Sound Pressure Level (dBA@1mtr) | 43 |
| O.U. Sound Pressure Level (dBA@1mtr) | 49 |
| O.U. Sound Power Level (dBA) | 67 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 9.52 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flareless (Indoor) / Flare (Outdoor) |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
| Model No. - Indoor | ASTG18KUCA |
| Model No. - Outdoor | AOTG18KUCA |
| Reverse Cycle System | Yes |
| Capacity Class | |
| Cooling Capacity (Watts) | 5,000 |
| Cooling Capacity (BTU/h) | 17,100 |
| Range (Watts) | 900-6,000 |
| Range (BTU/h) | 3,100-20,500 |
| Heating Capacity (Watts) | 6,000 |
| Heating Capacity (BTU/h) | 20,400 |
| Range (Watts) | 1,050-7,500 |
| Range (BTU/h) | 3,600-25,600 |
| Power Supply (Volts) | 240 |
| Phase-Frequency (Ph - Hz) | 1-50 |
| Power Supply Attachment | Outdoor |
| Plug Size (If Applicable) | |
| Running Current, Cooling (Amps) | 5.6 |
| Running Current, Range (Amps) | 9.5 |
| Input, Cooling (Watts) | 1,310 |
| Input, Range (Watts) | 210-2,200 |
| Running Current, Heating (Amps) | 6.7 |
| Running Current, Range (Amps) | 13.5 |
| Input, Heating (Watts) | 1,580 |
| Input, Range (Watts) | 200-3,100 |
| Input (Watts) |
| Moisture Removal (l/hr) | 2.6 |
| E.E.R. - Cooling | 3.82 |
| C.O.P. - Heating | 3.80 |
| Star Rating - Cooling | 3 |
| Star Rating - Heating | 3 |
| Fan Speed | 4 |
| Air Circulation, High (l/s) | 264 |
| Compressor Type | DC Rotary |
| Dimensions - Inside Unit (HxWxD mm) | 282x870x185 |
| Weight - Inside Unit (kg) | 9.5 |
| Dimensions - Outside Unit (HxWxD mm) | 620x790x290 |
| Weight - Outside Unit (kg) | 40 |
| I.U. Sound Pressure Level (dBA@1mtr) | 47 |
| O.U. Sound Pressure Level (dBA@1mtr) | 51 |
| O.U. Sound Power Level (dBA) | 68 |
| Refrigerant Type | R32 |
| Connection Pipe Sizes, Gas (mm) | 12.70 |
| Connection Pipe Sizes, Liquid (mm) | 6.35 |
| Pre Charged Length (Metre) | 20 |
| Minimum Pipe Length (Metre) | 3 |
| Maximum Pipe Length (Metre) | 20 |
| Maximum Pipe Height (Metre) | 15 |
| Pipe Connection Methods | Flareless (Indoor) / Flare (Outdoor) |
| Outdoor operating Temp, Cooling Degrees C | 10 to 46 |
| Outdoor operating Temp, Heating Degrees C | -15 to 24 |
